N/MS3108B20-18S

JAE Electronics
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Circular Connectors
Description Circular Connector
PDF
/
Buying Options
Total Price: USD $65.32
Unit Price: USD $65.3224
≥1 USD $65.3224
≥10 USD $59.93944
≥100 USD $52.639312
Inventory: 44
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0

Technical

Number of Contacts 9
Shell Size - Insert 20-18
Shell Finish Zinc
Current Rating 23A
Orientation N (Normal)
Current Rating (Amps) 13A 23A
Contact Finish - Mating Silver
Fastening Type Threaded
Voltage - Rated 500VAC
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Positions 9
Connector Type Plug, Female Sockets
Termination Solder Cup
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Backshell, Coupling Nut
Series N/MS
Published 2010
Packaging Bulk
Operating Temperature -55°C~125°C

Physical

Backshell Material, Plating Aluminum Alloy, Zinc
Insert Material Synthetic Resin
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line), Right Angle
Mount Free Hanging
Contact Plating Silver
Contact Material Copper Alloy

Supply Chain

Factory Lead Time 14 Weeks
