MS3108R32-1S
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
5 Position Circular Connector Plug, Female Sockets Solder Cup Silver
PDF
/
Inventory: 2128
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Material Copper
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line), Right Angle
Shell Material Aluminum Alloy
Body Material Aluminium
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2016
Series Military, MIL-DTL-5015, MS
JESD-609 Code e0
Feature Backshell, Coupling Nut
Pbfree Code no
Part Status Active
Termination Solder Cup
Connector Type Plug, Female Sockets
Number of Positions 5
Color Olive Drab
Gender Male
Voltage - Rated 900VAC 1250VDC
Fastening Type Threaded
Contact Finish - Mating Silver
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts YES
Option GENERAL PURPOSE
Current Rating (Amps) 41A 245A
Total Number of Contacts 5
Orientation N (Normal)
Ingress Protection Environment Resistant
Current Rating 245A
Shell Finish Olive Drab Cadmium
Shell Size - Insert 32-1
Mating Information MULTIPLE MATING PARTS AVAILABLE
Empty Shell NO
Backshell Type SOLID
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant
