MS3106E24-28S
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
GLOVE, POLYAMIDE, L/FREE, PU, SIZE 6 - More Details
PDF
/
Buying Options
Total Price: USD $108.1
Unit Price: USD $108.0992
≥1 USD $108.0992
≥10 USD $93.6848
≥100 USD $82.6584
≥500 USD $73.964
≥1000 USD $64.856
Inventory: 480
Minimum: 1
-
+
Technical Details
Compliance
Ratings Environment Resistant, IP67
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Technical
Number of Ports 1
Plating Aluminium, Cadmium, Chromate
Max Current Rating 22A
Contact Style Socket
Backshell Type SOLID
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
Shell Size - Insert 24-28
Shell Finish Olive Drab Cadmium
Military Standard MIL-C-5015
Current Rating 22A
Ingress Protection Environment Resistant
Orientation N (Normal)
Total Number of Contacts 24
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Silver
Fastening Type Threaded
HTS Code 8536.69.40.20
Voltage - Rated 200VAC 250VDC
Gender Female
Color Olive Drab
Number of Positions 24
Connector Type Plug, Female Sockets
ECCN Code EAR99
Termination Solder Cup
Part Status Active
Pbfree Code no
Feature Cable Clamp, Coupling Nut
JESD-609 Code e0
Series Military, MIL-DTL-5015, MS
Published 2000
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Material BRASS/COPPER ALLOY
Supply Chain
Factory Lead Time 12 Weeks
