MS3101F16-12S
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
CONN RCPT 1 POS FREE HNG W/SCKT
PDF
/
Inventory: 4009
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Environment Resistant
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Technical
Environmental Characteristics CORROSION RESISTANT
Body/Shell Style PLUG
Contact Style Socket
Backshell Type SOLID
Empty Shell NO
Shell Size - Insert 16-12
Shell Finish Olive Drab Cadmium
Military Standard MIL-C-5015
Current Rating 135A
Ingress Protection Environment Resistant
Orientation N (Normal)
Total Number of Contacts 1
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Silver
Fastening Type Threaded
Voltage - Rated 500VAC 700VDC
Gender Receptacle
Color Olive Drab
Number of Positions 1
Connector Type Receptacle, Female Sockets
Termination Solder Cup
Part Status Active
Feature Cable Clamp
Series Military, MIL-DTL-5015, MS
Published 2011
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Brass
