MS3101E28-12P
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
CONN RCPT MALE 26POS SOLDER CUP
PDF
/
Buying Options
Total Price: USD $154.9
Unit Price: USD $154.8976
≥1 USD $154.8976
≥10 USD $134.244
≥100 USD $118.4568
≥500 USD $105.9872
≥1000 USD $92.9368
Inventory: 59
Minimum: 1
-
+
Technical Details
Compliance
Ratings Environment Resistant
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Technical
Body/Shell Style PLUG
Contact Style Pin
Backshell Type SOLID
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
Shell Size - Insert 28-12
Shell Finish Olive Drab Cadmium
Military Standard MIL-C-5015
Current Rating 22A
Ingress Protection Environment Resistant
Orientation N (Normal)
Total Number of Contacts 26
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Silver
Fastening Type Threaded
HTS Code 8536.69.40.20
Voltage - Rated 500VAC 700VDC
Gender Male
Color Olive Drab
Number of Positions 26
Connector Type Receptacle, Male Pins
ECCN Code EAR99
Termination Solder Cup
Part Status Active
Pbfree Code no
Feature Cable Clamp
JESD-609 Code e0
Series Military, MIL-DTL-5015, MS
Published 2011
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Material BRASS/COPPER ALLOY
Supply Chain
Factory Lead Time 12 Weeks
