MS3100E18-1SW
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 4152
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Flanges, Panel, Wall
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum Alloy
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series Military, MIL-DTL-5015, MS
Feature Strain Relief
Part Status Active
Termination Solder Cup
ECCN Code EAR99
Connector Type Receptacle, Female Sockets
Number of Positions 10
Color Olive Drab
Gender Female
Voltage - Rated 200VAC 250VDC
HTS Code 8536.69.40.20
Fastening Type Threaded
Contact Finish - Mating Silver
Orientation W
Ingress Protection Environment Resistant
Depth 34.93mm
Current Rating 22A
Military Standard MIL-C-5015
Shell Finish Olive Drab Cadmium
Shell Size - Insert 18-1
Contact Style Socket
Max Current Rating 22A
Plating Cadmium, Chromate
Dimensions
Length 68.28mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant
