KPT06E20-16PDN
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
ITT CANNON KPT06E20-16PDN Circular Connector, KPT Series, MIL-DTL-26482 Series I Equivalent, Straight Plug, 16, Solder Pin
PDF
/
Inventory: 966
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum Alloy
Body Material Aluminium
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2014
Series KPT
Feature Shrink Boot Adapter
Part Status Active
Termination Solder Cup
Connector Type Plug, Male Pins
Number of Positions 16
Color Olive Drab
Gender Male
Voltage - Rated 1000VAC 1400VDC
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
Orientation N (Normal)
Ingress Protection Environment Resistant
Current Rating 13A
Shell Finish Olive Drab Cadmium
Shell Size - Insert 20-16
Contact Style Pin
Body Plating Cadmium
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant
