KPT00B16-26P
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
ITT CANNON KPT00B16-26P Circular Connector, KPT Series, MIL-DTL-26482 Series I Equivalent, Wall Mount Receptacle, 26
PDF
/
Inventory: 5451
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Copper
Mount Flanges, Panel, Wall
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum Alloy
Body Material Aluminium
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2014
Series KPT
Feature Strain Relief
Part Status Active
Termination Solder Cup
Connector Type Receptacle, Male Pins
Number of Positions 26
Color Olive Drab
Gender Male
Voltage - Rated 600VAC 850VDC
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
Orientation N (Normal)
Depth 31.3mm
Current Rating 7.5A
Shell Finish Olive Drab Cadmium
Shell Size - Insert 16-26
Max Current Rating 7.5A
Plating Cadmium, Chromate
Body Plating Cadmium
Dimensions
Length 48.2mm
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
