KPT00A8-4S
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
CONNECTOR, CIRCULAR, SIZE 8, 4WAY
PDF
/
Inventory: 7858
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Copper
Mount Flanges, Panel, Wall
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum Alloy
Body Material Aluminium
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2016
Series KPT
Part Status Active
Termination Solder Cup
Connector Type Receptacle, Female Sockets
Number of Positions 4
Color Olive Drab
Gender Receptacle
Voltage - Rated 600VAC 850VDC
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option WATER PROOF
Total Number of Contacts 4
Orientation N (Normal)
Depth 21mm
Current Rating 7.5A
Shell Finish Olive Drab Cadmium
Shell Size - Insert 8-4
Empty Shell NO
Backshell Type SOLID
Contact Style Socket
Plating Cadmium, Chromate
Body Plating Cadmium
Dimensions
Length 38mm
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
