KPSE7E16-23SDN
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 9169
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Plating Gold
Mount Bulkhead, Front Side Nut, Panel
Mounting Type Panel Mount
Mounting Feature Bulkhead - Front Side Nut
Shell Material Aluminum Alloy
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series KPSE
Feature Shrink Boot Adapter
Part Status Active
Termination Crimp
Connector Type Receptacle, Female Sockets
Number of Positions 23
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Color Olive Drab
Voltage - Rated 600VAC 850VDC
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
Current Rating (Amps) 7.5A 13A
Orientation N (Normal)
Ingress Protection Environment Resistant
Current Rating 13A
Shell Finish Olive Drab Cadmium
Shell Size - Insert 16-23
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant
