KPSE6E8-3APDN

ITT Cannon, LLC
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description STANDARD: MIL-DTL 26482 Circular Connector
PDF
/
Inventory: 2691
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant

Dimensions

Contact Finish Thickness - Mating 50.0μin 1.27μm

Technical

Contact Style Pin
Backshell Type SOLID
Empty Shell YES
Shell Size - Insert 8-3A
Shell Finish Olive Drab Cadmium
Ingress Protection Environment Resistant
Orientation N (Normal)
Total Number of Contacts 3
Current Rating (Amps) 7.5A
Option WATER PROOF
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Additional Feature STANDARD: MIL-DTL 26482
Voltage - Rated 600VAC 850VDC
Gender Male
Color Olive Drab
Number of Positions 3
Connector Type Plug, Male Pins
Termination Crimp
Part Status Active
Feature Shrink Boot Adapter
Series KPSE
Packaging Bulk
Operating Temperature -55°C~125°C

Physical

Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line)
