KPSE6E22-55SDX

ITT Cannon, LLC
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description ITT CANNON KPSE6E22-55SDX Circular Connector, KPSE Series, MIL-DTL-26482 Series I Equivalent, Straight Plug, 55, Crimp Socket
PDF
/
Inventory: 2898
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Ratings Environment Resistant
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC

Dimensions

Contact Finish Thickness - Mating 50.0μin 1.27μm

Technical

Body Plating Cadmium
Shell Size - Insert 22-55
Shell Finish Olive Drab Cadmium
Current Rating 7.5A
Ingress Protection Environment Resistant
Orientation N (Normal)
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Voltage - Rated 600VAC 850VDC
Gender Receptacle
Color Olive Drab
Number of Positions 55
Connector Type Plug, Female Sockets
Termination Crimp
Part Status Active
Series KPSE
Published 2011
Packaging Bulk
Operating Temperature -55°C~125°C

Physical

Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper

Supply Chain

Factory Lead Time 12 Weeks
