KPSE1E14-22SDZ
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 7702
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Environment Resistant
RoHS Status Non-RoHS Compliant
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Contact Style Socket
Number of Contacts 5
Shell Size - Insert 14-22
Shell Finish Olive Drab Cadmium
Current Rating 23A
Ingress Protection Environment Resistant
Shielding Shielded
Orientation N (Normal)
Current Rating (Amps) 7.5A 23A
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Voltage - Rated 600VAC 850VDC
Gender Female
Color Olive Drab
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Positions 5
Connector Type Receptacle, Female Sockets
Termination Crimp
Part Status Active
Feature Shrink Boot Adapter
Series KPSE
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Gold
