KPSE0E20-41PDN
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
ITT CANNON KPSE0E20-41PDN Circular Connector, KPSE Series, MIL-DTL-26482 Series I Equivalent, Wall Mount Receptacle, 41
PDF
/
Buying Options
Total Price: USD $100.72
Unit Price: USD $100.720353
≥1 USD $100.720353
≥10 USD $95.019203
≥100 USD $89.640762
≥500 USD $84.566756
≥1000 USD $79.779956
Inventory: 6059
Minimum: 1
-
+
Technical Details
Compliance
Ratings Environment Resistant
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Body Plating Cadmium
Contact Style Pin
Shell Size - Insert 20-41
Shell Finish Olive Drab Cadmium
Current Rating 7.5A
Ingress Protection Environment Resistant
Orientation N (Normal)
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
HTS Code 8536.69.40.20
Voltage - Rated 600VAC 850VDC
Gender Male
Color Olive Drab
Number of Positions 41
Connector Type Receptacle, Male Pins
ECCN Code EAR99
Termination Crimp
Part Status Active
Feature Shrink Boot Adapter
Series KPSE
Published 2016
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Feature Flange
Mounting Type Panel Mount
Mount Flanges, Panel
Contact Material Copper
Supply Chain
Factory Lead Time 12 Weeks
