KPSE0E14-5SDZ
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 5085
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Contact Style Socket
Backshell Type SOLID
Empty Shell YES
Shell Size - Insert 14-5
Shell Finish Olive Drab Cadmium
Ingress Protection Environment Resistant
Shielding Shielded
Orientation N (Normal)
Total Number of Contacts 5
Current Rating (Amps) 13A
Option WATER PROOF
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Voltage - Rated 1000VAC 1400VDC
Gender Female
Color Olive Drab
Number of Positions 5
Connector Type Receptacle, Female Sockets
Termination Crimp
Part Status Active
Feature Shrink Boot Adapter
Series KPSE
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Shell Material Aluminum Alloy
Mounting Feature Flange
Mounting Type Panel Mount
