KPSE08E14-5P

ITT Cannon, LLC
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description Circular Connector
PDF
/
Inventory: 4738
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line), Right Angle
Shell Material Aluminum Alloy

Technical

Operating Temperature -55°C~125°C
Packaging Bulk
Series KPSE
Feature Backshell
Part Status Active
Termination Crimp
ECCN Code EAR99
Connector Type Plug, Male Pins
Number of Positions 5
Color Olive Drab
Gender Male
Voltage - Rated 1000VAC 1400VDC
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option WATER PROOF
Total Number of Contacts 5
Orientation N (Normal)
Ingress Protection Environment Resistant
Current Rating 13A
Shell Finish Olive Drab Cadmium
Shell Size - Insert 14-5
Empty Shell YES
Backshell Type SOLID
Contact Style Pin
Max Current Rating 22A
Plating Cadmium, Chromate

Dimensions

Length 52.71mm
Contact Finish Thickness - Mating 50.0μin 1.27μm

Compliance

Radiation Hardening No
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant
