KPSE07F18-32PY
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
ITT CANNON KPSE07F18-32PY Circular Connector, KPSE Series, MIL-DTL-26482 Series I Equivalent, Jam Nut Receptacle, 32
PDF
/
Inventory: 7007
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Environment Resistant
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Length 48.4mm
Technical
Body Plating Cadmium
Plating Cadmium, Chromate
Max Current Rating 7.5A
Backshell Type SOLID
Empty Shell YES
Shell Size - Insert 18-32
Shell Finish Olive Drab Cadmium
Current Rating 7.5A
Depth 41.5mm
Ingress Protection Environment Resistant
Orientation Y
Total Number of Contacts 32
Option WATER PROOF
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
HTS Code 8536.69.40.20
Voltage - Rated 600VAC 850VDC
Gender Receptacle
Color Olive Drab
Number of Positions 32
Connector Type Receptacle, Male Pins
ECCN Code EAR99
Termination Crimp
Part Status Active
Feature Strain Relief
Series KPSE
Published 2016
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Feature Bulkhead - Front Side Nut
Mounting Type Panel Mount
Mount Bulkhead, Front Side Nut, Jam Nut, Panel
Contact Material Copper
Supply Chain
Factory Lead Time 12 Weeks
