KPSE06P20-39P
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
ITT CANNON KPSE06P20-39P Circular Connector, KPSE Series, MIL-DTL-26482 Series I Equivalent, Straight Plug, 39, Crimp Pin
PDF
/
Inventory: 5556
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum Alloy
Body Material Aluminium
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series KPSE
Feature Potted
Part Status Active
Termination Crimp
Connector Type Plug, Male Pins
Number of Positions 39
Color Olive Drab
Gender Male
Voltage - Rated 600VAC 850VDC
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
Current Rating (Amps) 7.5A 13A
Orientation N (Normal)
Ingress Protection Environment Resistant
Current Rating 13A
Shell Finish Olive Drab Cadmium
Shell Size - Insert 20-39
Plating Cadmium, Chromate
Body Plating Cadmium
Dimensions
Length 42.2mm
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant
