KPSE06B22-55S

ITT Cannon, LLC
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description ITT CANNON KPSE06B22-55S Circular Connector, KPSE Series, MIL-DTL-26482 Series I Equivalent, Straight Plug, 55, Crimp Socket
PDF
/
Inventory: 4219
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Contact Finish Thickness - Mating 50.0μin 1.27μm
Length 49mm

Technical

Body Plating Cadmium
Plating Cadmium, Chromate
Max Current Rating 7.5A
Shell Size - Insert 22-55
Shell Finish Olive Drab Cadmium
Current Rating 7.5A
Orientation N (Normal)
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Voltage - Rated 600VAC 850VDC
Gender Male
Color Olive Drab
Number of Positions 55
Connector Type Plug, Female Sockets
Termination Crimp
Part Status Active
Feature Strain Relief
Series KPSE
Published 2014
Packaging Bulk
Operating Temperature -55°C~125°C

Physical

Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Material Copper
