KPSE06B14-15SX
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
ITT CANNON KPSE06B14-15SX Circular Connector, KPSE Series, MIL-DTL-26482 Series I Equivalent, Straight Plug, 15, Crimp Socket
PDF
/
Buying Options
Total Price: USD $86.25
Unit Price: USD $86.252544
≥1 USD $86.252544
≥10 USD $81.370328
≥100 USD $76.764452
≥500 USD $72.419303
≥1000 USD $68.320096
Inventory: 8062
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Copper
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum Alloy
Body Material Aluminium
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2016
Series KPSE
Feature Strain Relief
Part Status Active
Termination Crimp
Connector Type Plug, Female Sockets
Number of Positions 15
Color Olive Drab
Gender Male
Voltage - Rated 600VAC 850VDC
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
Current Rating (Amps) 7.5A 13A
Orientation X
Current Rating 13A
Shell Finish Olive Drab Cadmium
Shell Size - Insert 14-15
Max Current Rating 7.5A
Plating Cadmium, Chromate
Body Plating Cadmium
Dimensions
Length 46mm
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
