KPSE01F20-39PW
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
STANDARD: MIL-C-26482POLARIZED COMPATIBLE CONTACTS: 430-8560-006; 430-8560-004 Circular Connector
PDF
/
Inventory: 8162
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Contact Finish Termination Gold (Au)
Coupling Type BAYONET
Termination Type CRIMP
Shell Size 20
Environmental Characteristics MOISTURE RESISTANT
Body/Shell Style PLUG
Contact Style Pin
Backshell Type SOLID
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 39
Shell Finish CHROMATE PLATED
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating GOLD
Additional Feature STANDARD: MIL-C-26482, POLARIZED, COMPATIBLE CONTACTS: 430-8560-006; 430-8560-004
Gender Male
Connector Type MIL SERIES CONNECTOR
Part Status Active
Pbfree Code no
JESD-609 Code e4
Packaging Bulk
Physical
Shell Material ALUMINUM ALLOY
Mounting Type CABLE
Contact Material COPPER ALLOY
Supply Chain
Factory Lead Time 12 Weeks
