KPSE01F18-32S
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
ITT CANNON KPSE01F18-32S Circular Connector, KPSE Series, MIL-DTL-26482 Series I Equivalent, Cable Mount Receptacle, 32
PDF
/
Inventory: 9145
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Environment Resistant
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Length 49mm
Technical
Body Plating Cadmium
Plating Cadmium, Chromate
Max Current Rating 7.5A
Environmental Characteristics MOISTURE RESISTANT
Body/Shell Style PLUG
Contact Style Socket
Backshell Type SOLID
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
Shell Size - Insert 18-32
Shell Finish Olive Drab Cadmium
Current Rating 7.5A
Depth 35.3mm
Ingress Protection Environment Resistant
Orientation N (Normal)
Total Number of Contacts 32
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Additional Feature STANDARD: MIL-C-26482, POLARIZED, COMPATIBLE CONTACTS: 031-8704-203
Voltage - Rated 600VAC 850VDC
Gender Female
Color Olive Drab
Number of Positions 32
Connector Type Receptacle, Female Sockets
Termination Crimp
Part Status Active
Pbfree Code no
Feature Strain Relief
JESD-609 Code e4
Series KPSE
Published 2014
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 12 Weeks
