KPSE01F14-12SDZ
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
ITT CANNON KPSE01F14-12SDZ Circular Connector, KPSE Series, MIL-DTL-26482 Series I Equivalent, Cable Mount Receptacle, 12
PDF
/
Inventory: 8383
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Environment Resistant
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Body Plating Cadmium
Contact Style Socket
Number of Contacts 12
Shell Size - Insert 14-12
Shell Finish Olive Drab Cadmium
Current Rating 13A
Ingress Protection Environment Resistant
Shielding Shielded
Orientation N (Normal)
Current Rating (Amps) 7.5A 13A
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Voltage - Rated 600VAC 850VDC
Gender Receptacle
Color Olive Drab
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Positions 12
Connector Type Receptacle, Female Sockets
Termination Crimp
Part Status Active
Feature Shrink Boot Adapter
Series KPSE
Published 2014
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Gold
Contact Material Copper
Supply Chain
Factory Lead Time 12 Weeks
