KPSE01A18-32SW
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
ITT CANNON KPSE01A18-32SW Circular Connector, KPSE Series, MIL-DTL-26482 Series I Equivalent, Cable Mount Receptacle, 32
PDF
/
Inventory: 6341
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Copper
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum Alloy
Body Material Aluminium
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2016
Series KPSE
Feature Backshell
Part Status Active
Termination Crimp
ECCN Code EAR99
Connector Type Receptacle, Female Sockets
Number of Positions 32
Color Olive Drab
Gender Female
Voltage - Rated 1000VAC 1400VDC
HTS Code 8536.69.40.20
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Total Number of Contacts 32
Orientation W
Current Rating 7.5A
Shell Finish Olive Drab Cadmium
Shell Size - Insert 18-32
Empty Shell YES
Backshell Type SOLID
Contact Style Socket
Body/Shell Style PLUG
Body Plating Cadmium
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
