KPSE00E14-5P
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
ITT CANNON KPSE00E14-5P Circular Connector, KPSE Series, MIL-DTL-26482 Series I Equivalent, Wall Mount Receptacle, 5
PDF
/
Buying Options
Total Price: USD $98.74
Unit Price: USD $98.737787
≥1 USD $98.737787
≥10 USD $93.148862
≥100 USD $87.876274
≥500 USD $82.902157
≥1000 USD $78.209573
Inventory: 9026
Minimum: 1
-
+
Technical Details
Compliance
Ratings Environment Resistant
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Length 32.5mm
Technical
Body Plating Cadmium
Plating Cadmium, Chromate
Max Current Rating 22A
Contact Style Pin
Shell Size - Insert 14-5
Shell Finish Olive Drab Cadmium
Current Rating 13A
Depth 29mm
Ingress Protection Environment Resistant
Orientation N (Normal)
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Voltage - Rated 1000VAC 1400VDC
Gender Receptacle
Color Olive Drab
Number of Positions 5
Connector Type Receptacle, Male Pins
Termination Crimp
Part Status Active
Feature Backshell
Series KPSE
Published 2013
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Feature Flange
Mounting Type Panel Mount
Mount Flanges, Panel, Wall
Contact Material Copper
Supply Chain
Factory Lead Time 12 Weeks
