KPSE00E10-6SDX

ITT Cannon, LLC
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description ITT CANNON KPSE00E10-6SDX Circular Connector, KPSE Series, MIL-DTL-26482 Series I Equivalent, Wall Mount Receptacle, 6
PDF
/
Buying Options
Total Price: USD $37.93
Unit Price: USD $37.927598
≥1 USD $37.927598
≥10 USD $35.780749
≥100 USD $33.755424
≥500 USD $31.844744
≥1000 USD $30.042212
Inventory: 7049
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Contact Material Copper
Mount Flanges, Panel
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum Alloy
Body Material Aluminium

Technical

Operating Temperature -55°C~125°C
Packaging Bulk
Published 2014
Series KPSE
Feature Backshell
Part Status Active
Termination Crimp
ECCN Code EAR99
Connector Type Receptacle, Female Sockets
Number of Positions 6
Color Olive Drab
Gender Receptacle
Voltage - Rated 600VAC 850VDC
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option WATER PROOF
Total Number of Contacts 6
Orientation N (Normal)
Ingress Protection Environment Resistant
Current Rating 7.5A
Shell Finish Olive Drab Cadmium
Shell Size - Insert 10-6
Empty Shell YES
Backshell Type SOLID
Body Plating Cadmium

Dimensions

Contact Finish Thickness - Mating 50.0μin 1.27μm

Compliance

REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant
