KJL6F21B35PN
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
ITT CANNON KJL6F21B35PN Circular Connector, MIL-C-38999 Series I, Plug, 79, Pin, Crimp, Cable
PDF
/
Inventory: 2386
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Environment Resistant
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Environmental Characteristics CORROSION/ENVIRONMENT/IMMERSION/MOISTURE RESISTANT
Contact Style Pin
Backshell Type SOLID
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
Shell Size - Insert 21-35
Shell Finish Olive Drab Cadmium
Ingress Protection Environment Resistant
Shielding Shielded
Orientation N (Normal)
Total Number of Contacts 79
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
HTS Code 8536.69.40.20
Gender Male
Color Olive Drab
Number of Positions 79
Connector Type Plug, Male Pins
ECCN Code EAR99
Termination Crimp
Part Status Active
Series KJL
Published 2011
Packaging Bulk
Operating Temperature -65°C~175°C
Physical
Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 8 Weeks
