KJL3T15N5SN
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
CONN RCPT FMALE 5POS GOLD CRIMP
PDF
/
Inventory: 3671
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Environment Resistant
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Environmental Characteristics ENVIRONMENT/IMMERSION/MOISTURE RESISTANT
Contact Style Socket
Backshell Type SOLID
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
Shell Size - Insert 15-5
Shell Finish Electroless Nickel
Ingress Protection Environment Resistant
Orientation N (Normal)
Total Number of Contacts 5
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Additional Feature STANDARD: MIL-DTL-38999
Gender Receptacle
Number of Positions 5
Connector Type Receptacle, Female Sockets
ECCN Code EAR99
Termination Crimp
Part Status Active
Series KJL
Published 2011
Packaging Bulk
Operating Temperature -65°C~200°C
Physical
Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Feature Flange
Mounting Type Panel Mount
Mount Flanges, Panel, Wall
Contact Material Copper
