KJ3T22B35PN
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
STANDARD: MIL-DTL-38999LOW PROFILE Circular Connector
PDF
/
Inventory: 5582
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Contact Material COPPER ALLOY
Mount Flanges, Panel, Wall
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum Alloy
Technical
Operating Temperature -65°C~175°C
Packaging Bulk
Series KJ
JESD-609 Code e4
Pbfree Code no
Part Status Active
Termination Crimp
Connector Type Receptacle, Male Pins
Number of Positions 100
Color Olive Drab
Gender Male
Additional Feature STANDARD: MIL-DTL-38999, LOW PROFILE
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 100
Orientation N (Normal)
Ingress Protection Environment Resistant
Shell Finish Olive Drab Cadmium
Shell Size - Insert 22-35
Mating Information MULTIPLE MATING PARTS AVAILABLE
Empty Shell NO
Backshell Type SOLID
Contact Style Pin
Environmental Characteristics ENVIRONMENT/FLUID/IMMERSION RESISTANT
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant
