CA3108R24-11SA206
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
ITT CANNON CA3108R24-11SA206Circular Connector, CA Series, MIL-DTL-5015 Series Equivalent, Right Angle Plug, 9 Contacts
PDF
/
Inventory: 3989
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper
Contact Plating Silver
Mount Free Hanging
Mounting Type Free Hanging (In-Line), Right Angle
Shell Material Aluminum Alloy
Body Material Aluminium
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2011
Series MIL-DTL-5015, CA
Feature Strain Relief
Part Status Active
Termination Solder Cup
Connector Type Plug, Female Sockets
Number of Positions 9
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Color Black
Gender Male
Voltage - Rated 50V
Fastening Type Threaded
Contact Finish - Mating Silver
Current Rating (Amps) 41A 74A
Orientation N (Normal)
Ingress Protection IP65 - Dust Tight, Water Resistant
Current Rating 74A
Shell Finish Black Zinc
Shell Size - Insert 24-11
Number of Contacts 9
Body Plating Cadmium
Compliance
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Ratings Dust Tight, IP65, Water Resistant
