CA3108F14S-7PX
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
CONN PLUG 3POS RT ANG W/PINS
PDF
/
Inventory: 1638
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Dust Tight, IP65, Water Resistant
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Technical
Environmental Characteristics CORROSION RESISTANT
Contact Style Pin
Backshell Type SOLID
Empty Shell NO
Shell Size - Insert 14S-7
Shell Finish Olive Drab Cadmium
Current Rating 22A
Ingress Protection IP65 - Dust Tight, Water Resistant
Orientation X
Total Number of Contacts 3
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Silver
Fastening Type Threaded
Additional Feature STANDARD: MIL-C-5015
Voltage - Rated 50V
Gender Male
Color Olive Drab
Number of Positions 3
Connector Type Plug, Male Pins
ECCN Code EAR99
Termination Solder Cup
Part Status Active
Pbfree Code no
Series MIL-DTL-5015, CA
Published 2013
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line), Right Angle
Mount Free Hanging
Contact Material Copper
