CA3108E36-3S
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
ITT CANNON CA3108E36-3S Circular Connector, MIL-C-5015 Series (VG95234), Plug, 6, Socket, Crimp, Cable
PDF
/
Inventory: 4472
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Dust Tight, IP65, Water Resistant
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Technical
Environmental Characteristics CORROSION RESISTANT
Contact Style Socket
Backshell Type SOLID
Empty Shell NO
Shell Size - Insert 36-3
Shell Finish Olive Drab Cadmium
Current Rating 245A
Ingress Protection IP65 - Dust Tight, Water Resistant
Orientation N (Normal)
Total Number of Contacts 6
Current Rating (Amps) 41A 245A
Option GENERAL PURPOSE
Mixed Contacts YES
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Silver
Fastening Type Threaded
Additional Feature STANDARD: MIL-C-5015
Voltage - Rated 50V
Gender Female
Color Olive Drab
Number of Positions 6
Connector Type Plug, Female Sockets
ECCN Code EAR99
Termination Solder Cup
Part Status Active
Pbfree Code no
Feature Strain Relief
Series MIL-DTL-5015, CA
Published 2016
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line), Right Angle
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 12 Weeks
