CA3108E22-12S
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
ITT CANNON CA3108E22-12S CIRCULAR, SIZE 22, 5WAYS, SKT
PDF
/
Inventory: 5968
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Dust Tight, IP65, Water Resistant
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Technical
Environmental Characteristics ENVIRONMENT RESISTANT; MOISTURE RESISTANT
Contact Style Socket
Backshell Type SOLID
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
Shell Size - Insert 22-12
Shell Finish Olive Drab Cadmium
Current Rating 74A
Ingress Protection IP65 - Dust Tight, Water Resistant
Orientation N (Normal)
Total Number of Contacts 5
Current Rating (Amps) 22A 74A
Option GENERAL PURPOSE
Mixed Contacts YES
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Silver
Fastening Type Threaded
Voltage - Rated 50V
Gender Female
Color Olive Drab
Number of Positions 5
Connector Type Plug, Female Sockets
Termination Solder Cup
Part Status Active
Feature Strain Relief
JESD-609 Code e4
Series MIL-DTL-5015, CA
Published 2016
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line), Right Angle
Mount Free Hanging
Contact Material Copper
