CA3108E18-9SW
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
STANDARD: MIL-C-5015 Circular Connector
PDF
/
Inventory: 9385
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material NOT SPECIFIED
Mount Free Hanging
Mounting Type Free Hanging (In-Line), Right Angle
Shell Material Aluminum Alloy
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series MIL-DTL-5015, CA
Feature Strain Relief
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder Cup
Connector Type Plug, Female Sockets
Number of Positions 7
Color Olive Drab
Gender Female
Voltage - Rated 50V
Additional Feature STANDARD: MIL-C-5015
Fastening Type Threaded
Contact Finish - Mating Silver
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 22A 41A
Total Number of Contacts 7
Orientation W
Ingress Protection IP65 - Dust Tight, Water Resistant
Current Rating 41A
Shell Finish Olive Drab Cadmium
Shell Size - Insert 18-9
Mating Information MULTIPLE MATING PARTS AVAILABLE
Empty Shell NO
Backshell Type SOLID
Contact Style Socket
Environmental Characteristics ENVIRONMENT RESISTANT; MOISTURE RESISTANT
Compliance
RoHS Status Non-RoHS Compliant
Ratings Dust Tight, IP65, Water Resistant
