CA3106R28-12PF80A95

ITT Cannon, LLC
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description ITT CANNON CA3106R28-12PF80A95Circular Connector, CA Series, MIL-DTL-5015 Series Equivalent, Straight Plug, 26 Contacts
PDF
/
Inventory: 7838
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Ratings Dust Tight, IP65, Water Resistant
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC

Dimensions

Contact Finish Thickness - Mating 20.0μin 0.51μm

Technical

Body Plating Cadmium
Number of Contacts 26
Shell Size - Insert 28-12
Shell Finish Olive Drab Cadmium
Current Rating 22A
Ingress Protection IP65 - Dust Tight, Water Resistant
Orientation N (Normal)
Current Rating (Amps) 22A
Contact Finish - Mating Gold
Fastening Type Threaded
Voltage - Rated 50V
Gender Male
Color Olive Drab
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Positions 26
Connector Type Plug, Male Pins
Termination Crimp
Part Status Active
Series MIL-DTL-5015, CA
Published 2013
Packaging Bulk
Operating Temperature -55°C~125°C

Physical

Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Silver
Contact Material Copper
