CA3106F24-6SA95
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
ITT CANNON CA3106F24-6SA95 Circular Connector, MIL-C-5015 Series (VG95234), Plug, 8, Socket, Crimp, Cable
PDF
/
Inventory: 9390
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Dust Tight, IP65, Water Resistant
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Dimensions
Contact Finish Thickness - Mating 20.0μin 0.51μm
Technical
Number of Contacts 8
Shell Size - Insert 24-6
Shell Finish Olive Drab Cadmium
Current Rating 41A
Ingress Protection IP65 - Dust Tight, Water Resistant
Orientation N (Normal)
Current Rating (Amps) 41A
Contact Finish - Mating Gold
Fastening Type Threaded
Voltage - Rated 50V
Gender Male
Color Olive Drab
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Positions 8
Connector Type Plug, Female Sockets
Termination Solder Cup
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series MIL-DTL-5015, CA
Published 2013
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Silver
Contact Material Copper
