CA3106F16S-1PF80A176
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
CONN PLUG 7POS INLINE W/PINS
PDF
/
Inventory: 4215
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Dust Tight, IP65, Water Resistant
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Dimensions
Contact Finish Thickness - Mating 19.7μin 0.50μm
Length 45mm
Technical
Plating Cadmium, Chromate
Max Current Rating 22A
Environmental Characteristics CORROSION RESISTANT
Contact Style Pin
Backshell Type SOLID
Empty Shell YES
Shell Size - Insert 16S-1
Shell Finish Olive Drab Cadmium
Current Rating 22A
Ingress Protection IP65 - Dust Tight, Water Resistant
Orientation N (Normal)
Total Number of Contacts 7
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Threaded
Additional Feature STANDARD: MIL-C-5015
Voltage - Rated 50V
Gender Male
Color Olive Drab
Number of Positions 7
Connector Type Plug, Male Pins
Termination Crimp
Part Status Active
Series MIL-DTL-5015, CA
Published 2013
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
