CA3106ER24-12PB
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
ITT CANNON CA3106ER24-12PB Circular Connector, MIL-C-5015 Series (VG95234), Plug, 5, Pin, Solder, Cable
PDF
/
Inventory: 2551
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Copper
Contact Plating Silver
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum Alloy
Body Material Aluminium
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2006
Series MIL-DTL-5015, CA-B
Part Status Active
Termination Solder Cup
Connector Type Plug, Male Pins
Number of Positions 5
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Color Olive Drab
Gender Male
Voltage - Rated 50V
Fastening Type Reverse Bayonet Lock
Contact Finish - Mating Silver
Current Rating (Amps) 41A 135A
Orientation N (Normal)
Ingress Protection IP67 - Dust Tight, Waterproof
Current Rating 135A
Shell Finish Olive Drab Cadmium
Shell Size - Insert 24-12
Number of Contacts 5
Compliance
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Ratings Dust Tight, IP67, Waterproof
