CA3106E36A98PB
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
ITT CANNON CA3106E36A98PB Circular Connector, CA-B Series, MIL-DTL-5015 Series Equivalent, Straight Plug, 39, Solder Pin
PDF
/
Inventory: 8198
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum Alloy
Body Material Aluminium
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2006
Series MIL-DTL-5015, CA-B
Feature Strain Relief
Part Status Active
Termination Solder Cup
Connector Type Plug, Male Pins
Number of Positions 39
Color Olive Drab
Gender Receptacle
Voltage - Rated 50V
Fastening Type Reverse Bayonet Lock
Contact Finish - Mating Silver
Current Rating (Amps) 22A 74A
Orientation N (Normal)
Ingress Protection IP67 - Dust Tight, Waterproof
Current Rating 74A
Shell Finish Olive Drab Cadmium
Shell Size - Insert 36-A98
Contact Style Pin
Body Plating Cadmium
Compliance
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Ratings Dust Tight, IP67, Waterproof
