CA3106E28-15PZDN

ITT Cannon, LLC
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description CIRCULAR, SIZE 28, 35WAYS, PIN
PDF
/
Inventory: 2199
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum Alloy
Body Material Aluminium

Technical

Operating Temperature -55°C~125°C
Packaging Bulk
Published 2013
Series MIL-DTL-5015, CA
JESD-609 Code e4
Feature Shrink Boot Adapter
Part Status Active
Termination Solder Cup
Connector Type Plug, Male Pins
Number of Positions 35
Color Olive Drab
Gender Male
Voltage - Rated 50V
Additional Feature STANDARD: MIL-C-5015
Fastening Type Threaded
Contact Finish - Mating Silver
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 35
Orientation Z
Ingress Protection IP65 - Dust Tight, Water Resistant
Current Rating 22A
Shell Finish Olive Drab Cadmium
Shell Size - Insert 28-15
Mating Information MULTIPLE MATING PARTS AVAILABLE
Empty Shell NO
Backshell Type SOLID
Environmental Characteristics ENVIRONMENT RESISTANT; MOISTURE RESISTANT

Compliance

REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Ratings Dust Tight, IP65, Water Resistant
