CA3106E24-6PYB15
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
ITT CANNON CA3106E24-6PYB15 Circular Connector, MIL-C-5015 Series (VG95234), Plug, 8, Pin, Crimp, Cable
PDF
/
Inventory: 930
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum Alloy
Body Material Aluminium
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2012
Series MIL-DTL-5015, CA-B
JESD-609 Code e4
Pbfree Code no
Part Status Active
Termination Crimp
Connector Type Plug, Male Pins
Number of Positions 8
Color Olive Drab
Gender Male
Voltage - Rated 50V
Fastening Type Reverse Bayonet Lock
Contact Finish - Mating Silver
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts YES
Option GENERAL PURPOSE
Total Number of Contacts 8
Orientation Y
Shielding Shielded
Ingress Protection IP67 - Dust Tight, Waterproof
Current Rating 41A
Shell Finish Olive Drab Cadmium
Shell Size - Insert 24-6
Mating Information MULTIPLE MATING PARTS AVAILABLE
Empty Shell NO
Backshell Type SOLID
Contact Style Pin
Environmental Characteristics ENVIRONMENT RESISTANT
Coupling Type THREADED
Compliance
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Ratings Dust Tight, IP67, Waterproof
