CA3106E22-19PX
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
STANDARD: MIL-C-5015 Circular Connector
PDF
/
Inventory: 9776
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum Alloy
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series MIL-DTL-5015, CA
JESD-609 Code e4
Feature Strain Relief
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder Cup
Connector Type Plug, Male Pins
Number of Positions 14
Color Olive Drab
Gender Male
Voltage - Rated 50V
Additional Feature STANDARD: MIL-C-5015
Fastening Type Threaded
Contact Finish - Mating Silver
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 14
Orientation X
Ingress Protection IP65 - Dust Tight, Water Resistant
Current Rating 22A
Shell Finish Olive Drab Cadmium
Shell Size - Insert 22-19
Mating Information MULTIPLE MATING PARTS AVAILABLE
Empty Shell NO
Backshell Type SOLID
Contact Style Pin
Environmental Characteristics ENVIRONMENT RESISTANT; MOISTURE RESISTANT
Compliance
RoHS Status Non-RoHS Compliant
Ratings Dust Tight, IP65, Water Resistant
