CA3106E22-14PX
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
ITT CANNON CA3106E22-14PX Circular Connector, CA Series, MIL-DTL-5015 Series Equivalent, Straight Plug, 19, Solder Pin
PDF
/
Inventory: 1843
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Dust Tight, IP65, Water Resistant
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Technical
Body Plating Cadmium
Contact Style Pin
Number of Contacts 19
Shell Size - Insert 22-14
Shell Finish Olive Drab Cadmium
Current Rating 22A
Ingress Protection IP65 - Dust Tight, Water Resistant
Orientation X
Current Rating (Amps) 22A
Contact Finish - Mating Silver
Fastening Type Threaded
Voltage - Rated 50V
Gender Male
Color Olive Drab
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Positions 19
Connector Type Plug, Male Pins
Termination Solder Cup
Part Status Active
Feature Strain Relief
Series MIL-DTL-5015, CA
Published 2006
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Silver
Contact Material Copper
