CA3106E16S-8PXF80
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
CONN PLUG 5POS INLINE W/PINS
PDF
/
Inventory: 3830
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum Alloy
Body Material Aluminium
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2013
Series MIL-DTL-5015, CA
JESD-609 Code e3
Feature Strain Relief
Part Status Active
Termination Crimp
Connector Type Plug, Male Pins
Number of Positions 5
Color Olive Drab
Gender Male
Voltage - Rated 50V
Fastening Type Threaded
Contact Finish - Mating Silver
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 5
Orientation X
Ingress Protection IP65 - Dust Tight, Water Resistant
Current Rating 22A
Shell Finish Olive Drab Cadmium
Shell Size - Insert 16S-8
Mating Information MULTIPLE MATING PARTS AVAILABLE
Empty Shell YES
Backshell Type SOLID
Contact Style Pin
Body Plating Cadmium
Compliance
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Ratings Dust Tight, IP65, Water Resistant
