CA3106E16-10S15A176
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
CONN PLUG 3POS INLINE W/SKTS
PDF
/
Inventory: 4253
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Dust Tight, IP65, Water Resistant
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Dimensions
Contact Finish Thickness - Mating 19.7μin 0.50μm
Technical
Body Plating Cadmium
Environmental Characteristics CORROSION RESISTANT
Contact Style Socket
Backshell Type SOLID
Empty Shell YES
Shell Size - Insert 16-10
Shell Finish Olive Drab Cadmium
Current Rating 41A
Ingress Protection IP65 - Dust Tight, Water Resistant
Shielding Shielded
Orientation N (Normal)
Total Number of Contacts 3
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Threaded
Voltage - Rated 50V
Gender Female
Color Olive Drab
Number of Positions 3
Connector Type Plug, Female Sockets
ECCN Code EAR99
Termination Crimp
Part Status Active
Series MIL-DTL-5015, CA
Published 2013
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
