CA3106E14S-5PF80DN
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
ITT CANNON CA3106E14S-5PF80DNCircular Connector, CA Series, MIL-DTL-5015 Series Equivalent, Straight Plug, 5 Contacts, Crimp Pin
PDF
/
Buying Options
Total Price: USD $37.83
Unit Price: USD $37.8312
≥1 USD $37.8312
≥10 USD $32.7888
≥100 USD $28.9256
≥500 USD $25.8808
≥1000 USD $22.6952
Inventory: 146
Minimum: 1
-
+
Technical Details
Compliance
Ratings Dust Tight, IP65, Water Resistant
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Technical
Body Plating Cadmium
Environmental Characteristics CORROSION RESISTANT
Backshell Type SOLID
Empty Shell YES
Shell Size - Insert 14S-5
Shell Finish Olive Drab Cadmium
Current Rating 22A
Ingress Protection IP65 - Dust Tight, Water Resistant
Orientation N (Normal)
Total Number of Contacts 5
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Silver
Fastening Type Threaded
Voltage - Rated 50V
Gender Male
Color Olive Drab
Number of Positions 5
Connector Type Plug, Male Pins
ECCN Code EAR99
Termination Crimp
Part Status Active
Feature Shrink Boot Adapter
Series MIL-DTL-5015, CA
Published 2006
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 12 Weeks
