CA3102E28-19S
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
ITT CANNON CA3102E28-19S Circular Connector, MIL-C-5015 Series (VG95234), Receptacle, 10, Socket, Solder, Panel
PDF
/
Inventory: 6264
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper
Mount Flanges, Panel
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum Alloy
Body Material Aluminium
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2013
Series MIL-DTL-5015, CA
Part Status Active
Termination Solder Cup
ECCN Code EAR99
Connector Type Receptacle, Female Sockets
Number of Positions 10
Color Olive Drab
Gender Receptacle
Voltage - Rated 50V
Additional Feature STANDARD: MIL-C-5015
HTS Code 8536.69.40.20
Fastening Type Threaded
Contact Finish - Mating Silver
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 22A 41A
Total Number of Contacts 10
Orientation N (Normal)
Ingress Protection IP65 - Dust Tight, Water Resistant
Current Rating 41A
Shell Finish Olive Drab Cadmium
Shell Size - Insert 28-19
Empty Shell NO
Backshell Type SOLID
Contact Style Socket
Environmental Characteristics CORROSION RESISTANT
Body Plating Cadmium
Compliance
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Ratings Dust Tight, IP65, Water Resistant
