CA3102E24-7PB04
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
CONN RCPT MALE 16POS SILVR CRIMP
PDF
/
Inventory: 8156
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Copper
Mount Flanges, Panel
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum Alloy
Body Material Aluminium
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2013
Series MIL-DTL-5015, CA-B
Part Status Active
Termination Crimp
Connector Type Receptacle, Male Pins
Number of Positions 16
Color Olive Drab
Gender Receptacle
Voltage - Rated 50V
Fastening Type Reverse Bayonet Lock
Contact Finish - Mating Silver
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 22A 41A
Total Number of Contacts 16
Orientation N (Normal)
Ingress Protection IP67 - Dust Tight, Waterproof
Current Rating 41A
Shell Finish Olive Drab Cadmium
Shell Size - Insert 24-7
Empty Shell NO
Backshell Type SOLID
Contact Style Pin
Environmental Characteristics CORROSION RESISTANT
Compliance
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Ratings Dust Tight, IP67, Waterproof
