CA3102E20-18PBF80A233
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 4936
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Dust Tight, IP67, Waterproof
RoHS Status Non-RoHS Compliant
Technical
Environmental Characteristics CORROSION RESISTANT
Contact Style Pin
Backshell Type SOLID
Empty Shell NO
Shell Size - Insert 20-18
Shell Finish Green Zinc Cobalt
Current Rating 41A
Ingress Protection IP67 - Dust Tight, Waterproof
Orientation N (Normal)
Total Number of Contacts 9
Current Rating (Amps) 22A 41A
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Silver
Fastening Type Reverse Bayonet Lock
Voltage - Rated 50V
Gender Male
Color Green
Number of Positions 9
Connector Type Receptacle, Male Pins
Termination Crimp
Part Status Active
Series MIL-DTL-5015, CA-B
Published 2013
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Shell Material Aluminum Alloy
Mounting Feature Flange
Mounting Type Panel Mount
Mount Flanges, Panel
