CA3101F36-A46PF16
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
ITT CANNON CA3101F36-A46PF16 Circular Connector, CA Series, MIL-DTL-5015 Series Equivalent, Cable Mount Receptacle, 27
PDF
/
Inventory: 7705
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Dust Tight, IP65, Water Resistant
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Technical
Body Plating Cadmium
Number of Contacts 27
Shell Size - Insert 36-A46
Shell Finish Olive Drab Cadmium
Current Rating 41A
Ingress Protection IP65 - Dust Tight, Water Resistant
Orientation N (Normal)
Current Rating (Amps) 41A
Contact Finish - Mating Silver
Fastening Type Threaded
Voltage - Rated 50V
Gender Male
Color Olive Drab
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Positions 27
Connector Type Receptacle, Male Pins
Termination Solder Cup
Part Status Active
Feature Dust Cap
Series MIL-DTL-5015, CA
Published 2013
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Plating Silver
Contact Material Copper
Supply Chain
Factory Lead Time 2 Weeks
